Hardware

Network standards

IEEE802.3, IEEE802.3u, IEEE802.3x,IEEE802.3ab

LED Indicator

6* Link/Act LED indicators
1 * Power LED indicator

Interfaces

4*10/100/1000 Base-TX Ethernet Ports(Data/Power)
2*10/100/1000 Base-TX Ethernet Port(Data)

Transmission media

Recommended: CAT5/5e UTP or better

Dimension

175*127*43mm(L*W*H)

Level of protection

4KV

Forwarding mode

Store-and-forward

Switch capacity

12G

Packet forwarding rate

8.9 Mpps

MAC address table

2K

PoE budget

Compatible with IEEE802.3af/at
Whole device: 55W

Input voltage

190-240V AC 50/60Hz

Mounting

Desktop mounting: support
Wall mounting: support
Rack mounting: Not support

Environment

Operating temperature: 0°C - 40°C
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%), non-condensing
Storage humidity: (5% - 90%), non-condensing
