| CPU | AMD Socket AM4, support for AMD Ryzen™ 5000 Series/5000 G-Series/4000 G-Series/3000 Series/3000 G-Series Processors
(Please refer "CPU Support List" for more information) |
| Chipset | AMD B550 |
| Memory | 4 x DDR4 DIMM sockets, up to 128 GB (32 GB per DIMM)
Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz
Dual channel memory architecture
ECC & non-ECC support
Extreme Memory Profile (XMP) support |
| Onboard Graphics | 1 x DisplayPort, max resolution 5120x2880@60Hz (DP1.4, HDCP2.3, HDR)
1 x HDMI port, max resolution 4096x2160@60Hz (HDMI2.1, HDCP2.3, HDR)
Maximum shared memory: 16 GB |
| Audio | Realtek® ALC1200 codec, High Definition Audio, 2/4/5.1/7.1-channel
Support for S/PDIF Out |
| LAN | Realtek® 2.5GbE LAN chip (2.5/1/0.1 Gbps) |
| Wireless | Intel® Wi-Fi 6 AX200, Dual-Band 2.4/5GHz, BLUETOOTH 5, 11ax 160MHz, up to 2.4 Gbps |
| Expansion Slots | 1 x PCIe x16 (CPU): AMD Ryzen™ 5000/3000 Series support PCIe4.0 x16, G-Series support PCIe3.0 x16
1 x PCIe x16 (Chipset, PCIEX2): PCIe3.0 x2
1 x PCIe x16 (Chipset, PCIEX1_2): PCIe3.0 x1
1 x PCIe x1 (Chipset, PCIEX1_1): PCIe3.0 x1 |
| Storage Interface | 1 x M.2 Socket 3 (CPU, 2242/2260/2280/22110, SATA & PCIe4.0 x4/x2, G/Series PCIe3.0 x4/x2)
1 x M.2 Socket 3 (Chipset, 2242/2260/2280/22110, SATA & PCIe3.0 x4/x2)
4 x SATA 6Gb/s connectors (RAID 0/1/10 supported) |
| USB | CPU: 2 x USB 3.2 Gen2 Type-A (red), 2 x USB 3.2 Gen1, 1 x USB 2.0/1.1 (back panel)
Chipset: 1 x USB Type-C™ (internal), 1 x USB 3.2 Gen1 (back), 2 x USB 3.2 Gen1 (internal), 2 x USB 2.0/1.1 (back), 4 x USB 2.0/1.1 (internal hub) |
| Internal I/O Connectors | 1 x 24-pin ATX main power
1 x 8-pin ATX 12V power
2 x M.2 Socket 3
4 x SATA 6Gb/s
1 x CPU fan header, 1 x water cooling CPU fan header, 3 x system fan headers
1 x CPU cooler LED/RGB header
2 x Addressable LED headers, 2 x RGB LED headers
1 x Front panel header, 1 x front panel audio header
1 x USB Type-C™ header (USB 3.2 Gen1), 1 x USB 3.2 Gen1 header, 2 x USB 2.0/1.1 headers
1 x TPM header (2x6 pin), 1 x Clear CMOS jumper |
| Back Panel Connectors | 1 x DisplayPort
1 x HDMI
2 x SMA antenna connectors (2T2R)
2 x USB 3.2 Gen2 Type-A / USB 3.2 Gen1 (red, CPU)
3 x USB 3.2 Gen1, 2 x USB 2.0/1.1
1 x Q-Flash Plus button
1 x RJ-45, 1 x optical S/PDIF Out
5 x Audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed, Water cooling flow rate, Overheating warning, Fan fail warning, Fan speed control
*Fan speed control depends on installed fan |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS
PnP1.0a, DMI2.7, WfM2.0, SMBIOS2.7, ACPI5.0 |
| Unique Features | APP Center*, @BIOS, EasyTune, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash, Q-Flash Plus
*Application support may vary by motherboard model |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | ATX; 30.5cm x 24.4cm |
