| CPU | AMD Socket AM5, support for AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors |
| Chipset | AMD B650 |
| Memory | Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s, 2 x DDR5 DIMM sockets supporting up to 128 GB, Dual channel, Non-ECC support, AMD EXPO™ & XMP support |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon™ Graphics support: 1 x D-Sub port (1920x1200@60Hz), 1 x HDMI port (4096x2160@60Hz), HDMI 2.1 & HDCP 2.3 support |
| Audio | Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | Realtek® Wi-Fi 6E RTL8852CE, WIFI a/b/g/n/ac/ax 2.4/5/6 GHz, BLUETOOTH 5.3, 11ax 160MHz support |
| Expansion Slots | 1 x PCIe x16 slot (CPU) PCIe 4.0 x16/x8/x4 mode, 1 x PCIe x1 slot (Chipset, PCIe 3.0 x1) |
| Storage Interface | 1 x M.2 (CPU, Socket 3, M key, type 2580/2280), 4 x SATA 6Gb/s connectors, RAID 0/1/10 for NVMe & SATA |
| USB | CPU: 2 x USB 3.2 Gen 1 ports, 1 x USB 2.0/1.1 port (back panel)
Chipset: 2 x USB 3.2 Gen 1 internal, 5 x USB 2.0/1.1 ports (3 back, 2 internal), 2 x USB 2.0/1.1 internal (Hub) |
| Internal I/O Connectors | 1 x 24-pin ATX main power, 1 x 8-pin ATX 12V, 1 x CPU fan, 2 x system fan, 2 x addressable LED headers, 1 x RGB LED header, 1 x M.2 Socket 3, 4 x SATA 6Gb/s, 1 x front panel, 1 x front panel audio, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x TPM header, 1 x Clear CMOS jumper |
| Back Panel Connectors | 4 x USB 2.0/1.1, 1 x PS/2 keyboard/mouse, 1 x D-Sub, 1 x Q-Flash Plus button, 2 x USB 3.2 Gen 1, 1 x HDMI, 1 x RJ-45, 3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus |
| Bundled Software | Norton® Internet Security (OEM version), LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX Form Factor; 24.0cm x 22.5cm |
