| CPU | LGA1700 socket: Support for 12th/13th/14th Gen Intel® Core™, Pentium® Gold, Celeron®
L3 cache varies with CPU
(Refer "CPU Support List" for details) |
| Chipset | Intel® B760 Express Chipset |
| Memory | 4 x DDR DIMM sockets, up to 128 GB (32 GB per DIMM)
DDR4 5333(O.C.) … 2133 MT/s
Dual channel, ECC (non-ECC mode) & non-ECC support
XMP support |
| Onboard Graphics | Intel® HD Graphics
1 x HDMI 4096x2160@60Hz (HDMI2.1, HDCP2.3)
1 x DisplayPort 4096x2304@60Hz (DP1.2, HDCP2.3)
Up to 2 displays simultaneously |
| Audio | Realtek® Audio CODEC, HD Audio, 2/4/5.1/7.1-channel
S/PDIF Out support (*configurable via software) |
| LAN | Realtek® GbE LAN (1G/100M) |
| Wireless | AMD Wi-Fi 6E RZ608 (BT 5.2), Intel Wi-Fi 6E AX210 & AX211 (BT 5.3), Realtek Wi-Fi 6E RTL8852CE (BT5.3)
2.4/5/6 GHz, 11ax support
(*Actual data rate may vary by environment) |
| Expansion Slots | CPU: 1 x PCIe x16 (PCIe4.0 x16)
Chipset: 4 x PCIe x16 (PCIe3.0 x1) |
| Storage Interface | CPU: 1 x M.2 (22110/2280 PCIe4.0 x4/x2)
Chipset: 1 x M.2 (2280 PCIe4.0 x4/x2)
4 x SATA6Gb/s, RAID 0/1/5/10 support |
| USB | 1 x USB Type-C 3.2 Gen2x2 (back), 1 x USB Type-C 3.2 Gen1 (internal)
1 x USB3.2 Gen2 Type-A (red, back)
2 x USB3.2 Gen1 (internal), 8 x USB2.0/1.1 (back + internal) |
| Internal I/O Connectors | 1 x 24-pin ATX, 1 x 8-pin ATX12V
CPU/system fan headers & water pump headers
2 x addressable LED, 2 x RGB LED
2 x M.2 Socket 3, 4 x SATA6Gb/s
Front panel/audio/S/PDIF headers, USB headers, TPM header, serial port
Q-Flash Plus, reset button/jumper, Clear CMOS |
| Back Panel Connectors | 1 x PS/2, 2 x SMA antenna, 1 x USB Type-C 3.2 Gen2x2
1 x USB3.2 Gen2 Type-A (red), 4 x USB2.0/1.1
1 x HDMI, 1 x DisplayPort, 1 x RJ-45, 3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed, Water flow, Fan fail, Fan speed control (*depends on installed fan/pump) |
| BIOS | 1 x 128 Mbit flash, AMI UEFI BIOS, PnP1.0a, DMI2.7, WfM2.0, SMBIOS2.7, ACPI5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus (*features may vary by model) |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | ATX; 30.5cm x 24.4cm |
